大家好，我是一名长期从事弱电智能化系统集成的项目负责人，拥有10年弱电智能化领域经验，专注日常项目涵盖综合布线、安防监控、门禁考勤、智慧楼宇、智能停车、园区企业网络建设。
[SW1]vlan batch 101 102 103 105
[SW1]int GigabitEthernet 0/0/1
[SW1-GigabitEthernet0/0/1]port link-type trunk
[SW1-GigabitEthernet0/0/1]port trunk allow-pass vlan 101 102 103 105
[SW1-GigabitEthernet0/0/1]q
[SW1]int Eth0/0/2
[SW1-Ethernet0/0/2]port link-type access
[SW1-Ethernet0/0/2]port default vlan 105
[SW1-Ethernet0/0/2]q
[SW1]int Eth0/0/3
[SW1-Ethernet0/0/3]port link-type access
[SW1-Ethernet0/0/3]port default vlan 101
[SW1-Ethernet0/0/3]q
[SW1]int e0/0/4
[SW1-Ethernet0/0/4]port link-type access
[SW1-Ethernet0/0/4]port default vlan 102
[SW1-Ethernet0/0/4]q
[SW1]int Eth0/0/5
[SW1-Ethernet0/0/5]port link-type access
[SW1-Ethernet0/0/5]port default vlan 103
[SW1-Ethernet0/0/5]q
[SW2]vlan 104
[SW2]int GigabitEthernet 0/0/1
[SW2-GigabitEthernet0/0/1]port link-type trunk
[SW2-GigabitEthernet0/0/1]port trunk allow-pass vlan 104
[SW2-GigabitEthernet0/0/1]undo port trunk allow-pass vlan 1
[SW2-GigabitEthernet0/0/1]q
[SW2]port-group group-member Ethernet 0/0/2 to Ethernet 0/0/3
[SW2-port-group]port link-type access
[SW2-Ethernet0/0/2]port link-type access
[SW2-Ethernet0/0/3]port link-type access
[SW2-port-group]port default vlan 104
[SW2-Ethernet0/0/2]port default vlan 104
[SW2-Ethernet0/0/3]port default vlan 104
[AR1-GigabitEthernet0/0/0]undo ip address
[AR1]int GigabitEthernet 0/0/0.101
[AR1-GigabitEthernet0/0/0.101]ip address 192.168.101.254 24
[AR1-GigabitEthernet0/0/0.101]dot1q termination vid 101
[AR1-GigabitEthernet0/0/0.101]arp broadcast enable
[AR1-GigabitEthernet0/0/0.101]dhcp select global
[AR1-GigabitEthernet0/0/0.101]q
[AR1]int GigabitEthernet 0/0/0.102
[AR1-GigabitEthernet0/0/0.102]ip address 192.168.102.254 24
[AR1-GigabitEthernet0/0/0.102]dot1q termination vid 102
[AR1-GigabitEthernet0/0/0.102]arp broadcast enable
[AR1-GigabitEthernet0/0/0.102]dhcp select global
[AR1-GigabitEthernet0/0/0.102]q
[AR1]interface GigabitEthernet 0/0/0.103
[AR1-GigabitEthernet0/0/0.103]ip address 192.168.103.254 24
[AR1-GigabitEthernet0/0/0.103]dot1q termination vid 103
[AR1-GigabitEthernet0/0/0.103]arp broadcast enable
[AR1-GigabitEthernet0/0/0.103]dhcp select global
[AR1-GigabitEthernet0/0/0.103]q
[AR1-GigabitEthernet0/0/1]undo ip address
[AR1]int GigabitEthernet 0/0/1.104
[AR1-GigabitEthernet0/0/1.104]ip address 192.168.104.254 24
[AR1-GigabitEthernet0/0/1.104]dot1q termination vid 104
[AR1-GigabitEthernet0/0/1.104]arp broadcast enable
[AR1-GigabitEthernet0/0/1.104]dhcp select global
[AR1-GigabitEthernet0/0/1.104]q
[AR1]int GigabitEthernet 0/0/0.105
[AR1-GigabitEthernet0/0/0.105]ip address 192.168.105.254 24
[AR1-GigabitEthernet0/0/0.105]dot1q termination vid 105
[AR1-GigabitEthernet0/0/0.105]arp broadcast enable
[AR1-GigabitEthernet0/0/0.105]dhcp select global
[AR1-GigabitEthernet0/0/0.105]q
[AR1]int GigabitEthernet 0/0/1.104
[AR1-GigabitEthernet0/0/1.104]ip address 192.168.104.254 24
[AR1-GigabitEthernet0/0/1.104]dot1q termination vid 104
[AR1-GigabitEthernet0/0/1.104]arp broadcast enable
[AR1-GigabitEthernet0/0/1.104]dhcp select global
[AR1-GigabitEthernet0/0/1.104]q
[AR1]ip pool vlan101
Info: It's successful to create an IP address pool.
[AR1-ip-pool-vlan101]network 192.168.101.0 mask 24
[AR1-ip-pool-vlan101]gateway-list 192.168.101.1
[AR1-ip-pool-vlan101]dns-list 202.96.134.133
[AR1-ip-pool-vlan101]lease day 0 hour 8 minute 0
[AR1]ip pool vlan102
Info: It's successful to create an IP address pool.
[AR1-ip-pool-vlan102]network 192.168.102.0 mask 24
[AR1-ip-pool-vlan102]gateway-list 192.168.102.254
[AR1-ip-pool-vlan102]dns-list 202.96.134.133
[AR1-ip-pool-vlan102]lease day 0 hour 8 minute 0
[AR1]ip pool vlan103
Info: It's successful to create an IP address pool.
[AR1-ip-pool-vlan103]network 192.168.103.0 mask 24
[AR1-ip-pool-vlan103]gateway-list 192.168.103.1
[AR1-ip-pool-vlan103]dns-list 202.96.134.133
[AR1-ip-pool-vlan103]lease day 0 hour 8 minute 0
[AR1]ip pool vlan104
Info: It's successful to create an IP address pool.
[AR1-ip-pool-vlan104]network 192.168.104.0 mask 24
[AR1-ip-pool-vlan104]gateway-list 192.168.104.254
[AR1-ip-pool-vlan104]dns-list 202.96.134.133
[AR1-ip-pool-vlan104]lease day 0 hour 8 minute 0
[AR1-ip-pool-vlan104]q
